Optical Power Meter 850/1300/1310/1490/1550/1625nm
Couldn't load pickup availability
The Orientek T25M Mini Optical Power Meter is a compact, high-precision fibre optic tester designed for fibre network installation, engineering acceptance, and maintenance. With automatic wavelength identification (AWI) and intelligent backlight control, it provides fast and accurate power measurements for both SM and MM fibres.
Key Features:
Pocket-Sized & Portable: Lightweight and compact design for easy handling.
6 Calibrated Wavelengths: Supports 850/1300/1310/1490/1550/1625nm.
Interchangeable Connectors: Versatile use across multiple fibre types.
Wide Measurement Range: Supports -70 to +10 dBm / -50 to +26 dBm.
Durable & User-Friendly: Rubber-armoured for protection with an easy-to-use interface.
Automatic Wavelength Identification & Switching: Works seamlessly with Orientek T15M Optical Light Source.
Long Battery Life: Up to 20 hours of continuous use with AAA batteries.
Technical Specifications:
- Detector Type: InGaAs
- Measurement Range: -70~+10dBm / -50~+26dBm
- Resolution: 0.01dBm
- Operating Temperature: -10°C to +60°C
- Storage Temperature: -25°C to +70°C
- Automatic Shutdown: After 10 minutes of inactivity
- Power Supply: 2x AAA 1.5V Batteries
- Dimensions: Length: 137mm, Width: 60mm, Depth: 37mm
- Weight: 180g
